Catálogo Korta

Diámetro nominal (mm) do

• 10
• 12
• 16
• 20
• 25
• 32
• 40
• 50
• 63
• 80
• 100
• 120
• 140
• 160
• 200

Paso (mm) Ph

• 2
• 4
• 5
• 6
• 8
• 10
• 12
• 16
• 20
• 25
• 30
• 32
• 35
• 40
• 50
• 60
• 64
• 80
• 100

Diámetro Bolas (mm) Dw

• 1.000
• 1.588
• 2.381
• 3.500
• 3.969
• 4.760
• 4.762
• 6.350
• 7.144
• 7.938
• 9.000
• 9.525
• 10.000
• 12.700
• 15.875
• 19.050

Referencia	Diámetro	Paso	Diám. Bola	Circuitos	D	CA	CO
1.2345678901234E+19	10	10	10.000	10	10	13	10
DBS-10010-4-7.144	100	10	7.144	4	125	98696	367751
DBS-10010-5-7.144	100	10	7.144	5	125	119576	459689
DBS-10010-6-7.144	100	10	7.144	6	125	139875	551626
BS-10010-4-7.144	100	10	7.144	4	125	98696	367751
BS-10010-5-7.144	100	10	7.144	5	125	119576	459689
BS-10010-6-7.144	100	10	7.144	6	125	139875	551626
DBS-10012-4-7.938	100	12	7.938	4	125	114371	408549
DBS-10012-5-7.938	100	12	7.938	5	125	138566	510686
DBS-10012-6-7.938	100	12	7.938	6	125	162090	612823
BS-10012-4-7.938	100	12	7.938	4	125	114371	408549
BS-10012-5-7.938	100	12	7.938	5	125	138566	510686
BS-10012-6-7.938	100	12	7.938	6	125	162090	612823
BS-10016-4-12.7	100	16	12.700	4	150	227486	696822
BS-10016-5-12.7	100	16	12.700	5	150	277141	878286
BS-10016-6-12.7	100	16	12.700	6	150	325378	1059750
DBS-10016-4-12.7	100	16	12.700	4	150	227486	696822
DBS-10016-5-12.7	100	16	12.700	5	150	277141	878286
DBS-10016-6-12.7	100	16	12.700	6	150	325378	1059750
DBS-10016-4-9.525	100	16	9.525	4	150	140671	457273
DBS-10016-5-9.525	100	16	9.525	5	150	170431	571592
DBS-10016-6-9.525	100	16	9.525	6	150	199363	685910
BS-10016-4-9.525	100	16	9.525	4	150	140671	457273
BS-10016-5-9.525	100	16	9.525	5	150	170431	571592
BS-10016-6-9.525	100	16	9.525	6	150	199363	685910
BS-10020-4-12.7	100	20	12.700	4	150	227435	696354
BS-10020-5-12.7	100	20	12.700	5	150	275550	870443
BS-10020-6-12.7	100	20	12.700	6	150	322326	1044532
DBS-10020-4-12.7	100	20	12.700	4	150	227435	696354
DBS-10020-5-12.7	100	20	12.700	5	150	275550	870443
DBS-10020-6-12.7	100	20	12.700	6	150	322326	1044532
DBS-10020-5-15.875	100	20	15.875	5	160	368066	1076765
DBS-10020-6-15.875	100	20	15.875	6	160	430549	1292118
DBS-10020-7-15.875	100	20	15.875	7	160	491583	1507472
DBS-10020-8-15.875	100	20	15.875	8	160	551404	1722825
BS-10020-5-15.875	100	20	15.875	5	160	368066	1076765
BS-10020-6-15.875	100	20	15.875	6	160	430549	1292118
BS-10020-7-15.875	100	20	15.875	7	160	491583	1507472
BS-10020-8-15.875	100	20	15.875	8	160	551404	1722825
DBS-10020-4-9.525	100	20	9.525	4	150	153733	522237
DBS-10020-5-9.525	100	20	9.525	5	150	187031	656876
DBS-10020-6-9.525	100	20	9.525	6	150	219384	791516
BS-10020-4-9.525	100	20	9.525	4	150	153733	522237
BS-10020-5-9.525	100	20	9.525	5	150	187031	656876
BS-10020-6-9.525	100	20	9.525	6	150	219384	791516
BS-10030-4-12.7	100	30	12.700	4	150	227259	694738
BS-10030-5-12.7	100	30	12.700	5	150	276864	875660
BS-10030-6-12.7	100	30	12.700	6	150	325053	1056581
DBS-10030-4-12.7	100	30	12.700	4	150	227259	694738
DBS-10030-5-12.7	100	30	12.700	5	150	276864	875660
DBS-10030-6-12.7	100	30	12.700	6	150	325053	1056581
DBS-10030-4-15.875	100	30	15.875	4	160	303568	859458
DBS-10030-5-15.875	100	30	15.875	5	160	367789	1074323
DBS-10030-6-15.875	100	30	15.875	6	160	430223	1289187
BS-10030-4-15.875	100	30	15.875	4	160	303568	859458
BS-10030-5-15.875	100	30	15.875	5	160	367789	1074323
BS-10030-6-15.875	100	30	15.875	6	160	430223	1289187
BS-10040-4-12.7	100	40	12.700	4	150	227014	692495
BS-10040-5-12.7	100	40	12.700	5	150	276566	872832
BS-10040-6-12.7	100	40	12.700	6	150	324703	1053169
DBS-10040-4-12.7	100	40	12.700	4	150	227014	692495
DBS-10040-5-12.7	100	40	12.700	5	150	276566	872832
DBS-10040-6-12.7	100	40	12.700	6	150	324703	1053169
DBS-10040-3-15.875	100	40	15.875	3	160	228400	608740
DBS-10040-4-15.875	100	40	15.875	4	160	303248	856745
BS-10040-3-15.875	100	40	15.875	3	160	228400	608740
BS-10040-4-15.875	100	40	15.875	4	160	303248	856745
DBS-10040-3-9.525	100	40	9.525	3	150	121468	397557
DBS-10040-4-9.525	100	40	9.525	4	150	156620	535485
DBS-10040-5-9.525	100	40	9.525	5	150	190520	673413
BS-10040-3-9.525	100	40	9.525	3	150	121468	397557
BS-10040-4-9.525	100	40	9.525	4	150	156620	535485
BS-10040-5-9.525	100	40	9.525	5	150	190520	673413
DBS-10064-2-9.525	100	64	9.525	2	150	84209	256611
BS-1204-2-2.381	12	4	2.381	2	24	3956	5591
BS-1204-3-2.381	12	4	2.381	3	24	5606	8387
BS-1204-4-2.381	12	4	2.381	4	24	7180	11183
DBS-1204-2-2.381	12	4	2.381	2	24	3956	5591
DBS-1204-3-2.381	12	4	2.381	3	24	5606	8387
DBS-1204-4-2.381	12	4	2.381	4	24	7180	11183
BS-1205-2-2.381	12	5	2.381	2	24	3953	5576
BS-1205-3-2.381	12	5	2.381	3	24	5601	8364
DBS-1205-2-2.381	12	5	2.381	2	24	3953	5576
DBS-1205-3-2.381	12	5	2.381	3	24	5601	8364
DBS-12010-5-7.144	120	10	7.144	5	150	130264	563201
DBS-12010-6-7.144	120	10	7.144	6	150	152378	675841
DBS-12010-7-7.144	120	10	7.144	7	150	173978	788482
BS-12010-5-7.144	120	10	7.144	5	150	130264	563201
BS-12010-6-7.144	120	10	7.144	6	150	152378	675841
BS-12010-7-7.144	120	10	7.144	7	150	173978	788482
DBS-12012-5-7.938	120	12	7.938	5	150	150875	624303
DBS-12012-6-7.938	120	12	7.938	6	150	176486	749163
DBS-12012-7-7.938	120	12	7.938	7	150	201505	874024
BS-12012-5-7.938	120	12	7.938	5	150	150875	624303
BS-12012-6-7.938	120	12	7.938	6	150	176486	749163
BS-12012-7-7.938	120	12	7.938	7	150	201505	874024
DBS-12016-4-9.525	120	16	9.525	4	170	155828	571802
DBS-12016-5-9.525	120	16	9.525	5	170	188794	714753
DBS-12016-6-9.525	120	16	9.525	6	170	220843	857703
BS-12016-4-9.525	120	16	9.525	4	170	155828	571802
BS-12016-5-9.525	120	16	9.525	5	170	188794	714753
BS-12016-6-9.525	120	16	9.525	6	170	220843	857703
DBS-12020-4-12.7	120	20	12.700	4	170	247638	841893
DBS-12020-5-12.7	120	20	12.700	5	170	301404	1059624
DBS-12020-6-12.7	120	20	12.700	6	170	353641	1277355
BS-12020-4-12.7	120	20	12.700	4	170	247638	841893
BS-12020-5-12.7	120	20	12.700	5	170	301404	1059624
BS-12020-6-12.7	120	20	12.700	6	170	353641	1277355
DBS-12020-5-15.875	120	20	15.875	5	200	403661	1304151
DBS-12020-6-15.875	120	20	15.875	6	200	472185	1564981
DBS-12020-7-15.875	120	20	15.875	7	200	539121	1825811
DBS-12020-8-15.875	120	20	15.875	8	200	604728	2086641
BS-12020-5-15.875	120	20	15.875	5	200	403661	1304151
BS-12020-6-15.875	120	20	15.875	6	200	472185	1564981
BS-12020-7-15.875	120	20	15.875	7	200	539121	1825811
BS-12020-8-15.875	120	20	15.875	8	200	604728	2086641
DBS-12030-4-15.875	120	30	15.875	4	200	332998	1041646
DBS-12030-5-15.875	120	30	15.875	5	200	403445	1302057
DBS-12030-6-15.875	120	30	15.875	6	200	471933	1562468
BS-12030-4-15.875	120	30	15.875	4	200	332998	1041646
BS-12030-5-15.875	120	30	15.875	5	200	403445	1302057
BS-12030-6-15.875	120	30	15.875	6	200	471933	1562468
DBS-12040-3-12.7	120	40	12.700	3	170	191626	621719
DBS-12040-4-12.7	120	40	12.700	4	170	247314	838598
DBS-12040-5-12.7	120	40	12.700	5	170	301010	1055477
BS-12040-3-12.7	120	40	12.700	3	170	191626	621719
BS-12040-4-12.7	120	40	12.700	4	170	247314	838598
BS-12040-5-12.7	120	40	12.700	5	170	301010	1055477
DBS-12040-3-15.875	120	40	15.875	3	200	252231	745595
DBS-12040-4-15.875	120	40	15.875	4	200	332749	1039314
BS-12040-3-15.875	120	40	15.875	3	200	252231	745595
BS-12040-4-15.875	120	40	15.875	4	200	332749	1039314
DBS-12064-2-12.7	120	64	12.700	2	170	135893	415933
DBS-14010-5-7.144	140	10	7.144	5	170	139616	666706
DBS-14010-6-7.144	140	10	7.144	6	170	163318	800047
DBS-14010-7-7.144	140	10	7.144	7	170	186469	933388
DBS-14010-8-7.144	140	10	7.144	8	170	209160	1066729
BS-14010-5-7.144	140	10	7.144	5	170	139616	666706
BS-14010-6-7.144	140	10	7.144	6	170	163318	800047
BS-14010-7-7.144	140	10	7.144	7	170	186469	933388
BS-14010-8-7.144	140	10	7.144	8	170	209160	1066729
DBS-14020-5-12.7	140	20	12.700	5	195	321288	1234228
DBS-14020-6-12.7	140	20	12.700	6	195	375829	1481073
DBS-14020-7-12.7	140	20	12.700	7	195	429106	1727919
DBS-14020-8-12.7	140	20	12.700	8	195	481324	1974764
BS-14020-5-12.7	140	20	12.700	5	195	321288	1234228
BS-14020-6-12.7	140	20	12.700	6	195	375829	1481073
BS-14020-7-12.7	140	20	12.700	7	195	429106	1727919
BS-14020-8-12.7	140	20	12.700	8	195	481324	1974764
DBS-14020-5-15.875	140	20	15.875	5	210	434330	1531465
DBS-14020-6-15.875	140	20	15.875	6	210	508060	1837758
DBS-14020-7-15.875	140	20	15.875	7	210	580083	2144051
DBS-14020-8-15.875	140	20	15.875	8	210	650673	2450344
BS-14020-5-15.875	140	20	15.875	5	210	434330	1531465
BS-14020-6-15.875	140	20	15.875	6	210	508060	1837758
BS-14020-7-15.875	140	20	15.875	7	210	580083	2144051
BS-14020-8-15.875	140	20	15.875	8	210	650673	2450344
BS-14030-6-12.7	140	30	12.700	6	195	375676	1479273
DBS-14030-4-12.7	140	30	12.700	4	195	265079	986182
DBS-14030-5-12.7	140	30	12.700	5	195	321158	1232728
DBS-14030-6-12.7	140	30	12.700	6	195	375676	1479273
BS-14030-4-12.7	140	30	12.700	4	195	265079	986182
BS-14030-5-12.7	140	30	12.700	5	195	321158	1232728
BS-14030-4-15.875	140	30	15.875	4	210	358346	1223707
BS-14030-5-15.875	140	30	15.875	5	210	434156	1529634
BS-14030-6-15.875	140	30	15.875	6	210	507858	1835561
DBS-14030-4-15.875	140	30	15.875	4	210	358346	1223707
DBS-14030-5-15.875	140	30	15.875	5	210	434156	1529634
DBS-14030-6-15.875	140	30	15.875	6	210	507858	1835561
BS-14030-4-19.05	140	30	19.050	4	225	465200	1501125
BS-14030-5-19.05	140	30	19.050	5	225	563615	1876406
BS-14030-6-19.05	140	30	19.050	6	225	659294	2251688
DBS-14030-4-19.05	140	30	19.050	4	225	465200	1501125
DBS-14030-5-19.05	140	30	19.050	5	225	563615	1876406
DBS-14030-6-19.05	140	30	19.050	6	225	659294	2251688
BS-14040-3-12.7	140	40	12.700	3	195	202786	716665
BS-14040-4-12.7	140	40	12.700	4	195	264929	984509
DBS-14040-3-12.7	140	40	12.700	3	195	202786	716665
DBS-14040-4-12.7	140	40	12.700	4	195	264929	984509
BS-14040-3-15.875	140	40	15.875	3	210	272701	882314
BS-14040-4-15.875	140	40	15.875	4	210	358148	1221666
DBS-14040-3-15.875	140	40	15.875	3	210	272701	882314
DBS-14040-4-15.875	140	40	15.875	4	210	358148	1221666
BS-14040-3-19.05	140	40	19.050	3	225	352439	1075122
BS-14040-4-19.05	140	40	19.050	4	225	464945	1498655
DBS-14040-3-19.05	140	40	19.050	3	225	352439	1075122
DBS-14040-4-19.05	140	40	19.050	4	225	464945	1498655
BS-1610-2-3.5	16	10	3.500	2	28	7965	11935
BS-1610-3-3.5	16	10	3.500	3	28	11288	17903
BS-1610-4-3.5	16	10	3.500	4	28	14456	23871
DBS-1610-2-3.5	16	10	3.500	2	28	7965	11935
DBS-1610-3-3.5	16	10	3.500	3	28	11288	17903
DBS-1610-4-3.5	16	10	3.500	4	28	14456	23871
BS-1602-3-1.5875	16	2	1.588	3	28	4680	10439
DBS-1602-3-1.5875	16	2	1.588	3	28	4680	10439
BS-1620-2-2.381	16	20	2.381	2	32	5695	10022
BS-1620-4-2.381	16	20	2.381	4	32	10338	20043
BS-1604-2-2.381	16	4	2.381	2	28	5056	8660
BS-1604-3-2.381	16	4	2.381	3	28	7165	12989
BS-1604-4-2.381	16	4	2.381	4	28	9176	17319
DBS-1604-2-2.381	16	4	2.381	2	28	5056	8660
DBS-1604-3-2.381	16	4	2.381	3	28	7165	12989
DBS-1604-4-2.381	16	4	2.381	4	28	9176	17319
KBS-1605	16	5	3.500	3	28	11336	18135
BS-1605-3-3.5	16	5	3.500	3	28	11336	18135
BS-1605-4-3.5	16	5	3.500	4	28	14519	24180
KBS-1605	16	5	3.500	3	28	11336	18135
EDBS-1605	16	5	3.500	2	28	7999	12090
DBS-1605-3-3.5	16	5	3.500	3	28	11336	18135
DBS-1605-4-3.5	16	5	3.500	4	28	14519	24180
EDBS-1605	16	5	3.500	2	28	7999	12090
BS-16010-5-7.144	160	10	7.144	5	185	147990	770205
BS-16010-6-7.144	160	10	7.144	6	185	173113	924246
BS-16010-7-7.144	160	10	7.144	7	185	197654	1078287
BS-16010-8-7.144	160	10	7.144	8	185	221706	1232327
DBS-16010-5-7.144	160	10	7.144	5	185	147990	770205
DBS-16010-6-7.144	160	10	7.144	6	185	173113	924246
DBS-16010-7-7.144	160	10	7.144	7	185	197654	1078287
DBS-16010-8-7.144	160	10	7.144	8	185	221706	1232327
BS-16020-5-12.7	160	20	12.700	5	210	340231	1416047
BS-16020-6-12.7	160	20	12.700	6	210	397988	1699257
BS-16020-7-12.7	160	20	12.700	7	210	454405	1982466
BS-16020-8-12.7	160	20	12.700	8	210	509703	2265676
DBS-16020-5-12.7	160	20	12.700	5	210	340231	1416047
DBS-16020-6-12.7	160	20	12.700	6	210	397988	1699257
DBS-16020-7-12.7	160	20	12.700	7	210	454405	1982466
DBS-16020-8-12.7	160	20	12.700	8	210	509703	2265676
BS-16020-5-15.875	160	20	15.875	5	225	461465	1758732
BS-16020-6-15.875	160	20	15.875	6	225	539803	2110478
BS-16020-7-15.875	160	20	15.875	7	225	616324	2462224
BS-16020-8-15.875	160	20	15.875	8	225	691325	2813971
DBS-16020-5-15.875	160	20	15.875	5	225	461465	1758732
DBS-16020-6-15.875	160	20	15.875	6	225	539803	2110478
DBS-16020-7-15.875	160	20	15.875	7	225	616324	2462224
DBS-16020-8-15.875	160	20	15.875	8	225	691325	2813971
BS-16030-4-12.7	160	30	12.700	4	210	280734	1131775
BS-16030-5-12.7	160	30	12.700	5	210	340124	1414719
BS-16030-6-12.7	160	30	12.700	6	210	397863	1697663
DBS-16030-4-12.7	160	30	12.700	4	210	280734	1131775
DBS-16030-5-12.7	160	30	12.700	5	210	340124	1414719
DBS-16030-6-12.7	160	30	12.700	6	210	397863	1697663
BS-16030-4-15.875	160	30	15.875	4	225	380770	1405685
BS-16030-5-15.875	160	30	15.875	5	225	461323	1757106
BS-16030-6-15.875	160	30	15.875	6	225	539636	2108527
DBS-16030-4-15.875	160	30	15.875	4	225	380770	1405685
DBS-16030-5-15.875	160	30	15.875	5	225	461323	1757106
DBS-16030-6-15.875	160	30	15.875	6	225	539636	2108527
BS-16030-4-19.05	160	30	19.050	4	235	490685	1697738
BS-16030-5-19.05	160	30	19.050	5	235	594491	2122173
BS-16030-6-19.05	160	30	19.050	6	235	695411	2546607
DBS-16030-4-19.05	160	30	19.050	4	235	490685	1697738
DBS-16030-5-19.05	160	30	19.050	5	235	594491	2122173
DBS-16030-6-19.05	160	30	19.050	6	235	695411	2546607
BS-16040-3-12.7	160	40	12.700	3	210	215346	825983
BS-16040-4-12.7	160	40	12.700	4	210	280611	1130293
DBS-16040-3-12.7	160	40	12.700	3	210	215346	825983
DBS-16040-4-12.7	160	40	12.700	4	210	280611	1130293
BS-16040-3-15.875	160	40	15.875	3	225	290760	1018938
BS-16040-4-15.875	160	40	15.875	4	225	380606	1403870
DBS-16040-3-15.875	160	40	15.875	3	225	290760	1018938
DBS-16040-4-15.875	160	40	15.875	4	225	380606	1403870
BS-16040-3-19.05	160	40	19.050	3	235	373091	1222769
BS-16040-4-19.05	160	40	19.050	4	235	490476	1695573
DBS-16040-3-19.05	160	40	19.050	3	235	373091	1222769
DBS-16040-4-19.05	160	40	19.050	4	235	490476	1695573
BS-2010-2-3.5	20	10	3.500	2	36	9540	16371
BS-2010-3-3.5	20	10	3.500	3	36	13520	24557
BS-2010-4-3.5	20	10	3.500	4	36	17315	32743
DBS-2010-2-3.5	20	10	3.500	2	36	9540	16371
DBS-2010-3-3.5	20	10	3.500	3	36	13520	24557
DBS-2010-4-3.5	20	10	3.500	4	36	17315	32743
BS-2002-3-1,5875	20	2	1.588	3	36	5163	13166
DBS-2002-3-1.5875	20	2	1.588	3	36	5163	13166
BS-2020-2-3.5	20	20	3.500	2	36	10258	17959
BS-2020-4-3.5	20	20	3.500	4	36	18619	35918
BSL-2020	20	20	3.500	2	36	9436	17959
DBS-2020-2-3.5	20	20	3.500	2	36	10258	17959
BS-2004-2-2.381	20	4	2.381	2	36	5734	11218
BS-2004-3-2.381	20	4	2.381	3	36	8126	16827
BS-2004-4-2.381	20	4	2.381	4	36	10408	22436
DBS-2004-2-2.381	20	4	2.381	2	36	5734	11218
DBS-2004-3-2.381	20	4	2.381	3	36	8126	16827
DBS-2004-4-2.381	20	4	2.381	4	36	10408	22436
BS-2005-2-3.5	20	5	3.500	2	36	9136	15410
KBS-2005	20	5	3.500	3	36	12949	23116
BS-2005-4-3.5	20	5	3.500	4	36	16584	30821
RBS-2005	20	5	3.500	3	35	12994	23116
RS-2005	20	5	3.500	3	35	12949	23116
KBS-2005	20	5	3.500	3	36	12949	23116
EDBS-2005	20	5	3.500	3	36	12949	23116
DBS-2005-2-3.5	20	5	3.500	2	36	9136	15410
EDBS-2005	20	5	3.500	3	36	12949	23116
DBS-2005-4-3.5	20	5	3.500	4	36	16584	30821
BS-20010-5-7.144	200	10	7.144	5	225	161356	965696
BS-20010-6-7.144	200	10	7.144	6	225	188748	1158835
BS-20010-7-7.144	200	10	7.144	7	225	215504	1351975
BS-20010-8-7.144	200	10	7.144	8	225	241729	1545114
DBS-20010-5-7.144	200	10	7.144	5	225	161356	965696
DBS-20010-6-7.144	200	10	7.144	6	225	188748	1158835
DBS-20010-7-7.144	200	10	7.144	7	225	215504	1351975
DBS-20010-8-7.144	200	10	7.144	8	225	241729	1545114
BS-20020-5-12.7	200	20	12.700	5	255	373206	1779609
BS-20020-6-12.7	200	20	12.700	6	255	436561	2135531
BS-20020-7-12.7	200	20	12.700	7	255	498448	2491453
BS-20020-8-12.7	200	20	12.700	8	255	559104	2847375
DBS-20020-5-12.7	200	20	12.700	5	255	373206	1779609
DBS-20020-6-12.7	200	20	12.700	6	255	436561	2135531
DBS-20020-7-12.7	200	20	12.700	7	255	498448	2491453
DBS-20020-8-12.7	200	20	12.700	8	255	559104	2847375
BS-20020-5-15.875	200	20	15.875	5	270	508336	2213174
BS-20020-6-15.875	200	20	15.875	6	270	594631	2655809
BS-20020-7-15.875	200	20	15.875	7	270	678925	3098444
BS-20020-8-15.875	200	20	15.875	8	270	761544	3541079
DBS-20020-5-15.875	200	20	15.875	5	270	508336	2213174
DBS-20020-6-15.875	200	20	15.875	6	270	594631	2655809
DBS-20020-7-15.875	200	20	15.875	7	270	678925	3098444
DBS-20020-8-15.875	200	20	15.875	8	270	761544	3541079
BS-20030-4-12.7	200	30	12.700	4	255	307978	1422823
BS-20030-5-12.7	200	30	12.700	5	255	373131	1778529
BS-20030-6-12.7	200	30	12.700	6	255	436473	2134235
DBS-20030-4-12.7	200	30	12.700	4	255	307978	1422823
DBS-20030-5-12.7	200	30	12.700	5	255	373131	1778529
DBS-20030-6-12.7	200	30	12.700	6	255	436473	2134235
BS-20030-4-15.875	200	30	15.875	4	270	419490	1769477
BS-20030-5-15.875	200	30	15.875	5	270	508235	2211847
BS-20030-6-15.875	200	30	15.875	6	270	594511	2654216
DBS-20030-4-15.875	200	30	15.875	4	270	419490	1769477
DBS-20030-5-15.875	200	30	15.875	5	270	508235	2211847
DBS-20030-6-15.875	200	30	15.875	6	270	594511	2654216
BS-20030-4-19.05	200	30	19.050	4	280	545835	2156063
BS-20030-5-19.05	200	30	19.050	5	280	661309	2695078
BS-20030-6-19.05	200	30	19.050	6	280	773571	3234094
DBS-20030-4-19.05	200	30	19.050	4	280	545835	2156063
DBS-20030-5-19.05	200	30	19.050	5	280	661309	2695078
DBS-20030-6-19.05	200	30	19.050	6	280	773571	3234094
BS-20040-3-12.7	200	40	12.700	3	255	237126	1044453
BS-20040-4-12.7	200	40	12.700	4	255	307890	1421616
DBS-20040-3-12.7	200	40	12.700	3	255	237126	1044453
DBS-20040-4-12.7	200	40	12.700	4	255	307890	1421616
BS-20040-3-15.875	200	40	15.875	3	270	321835	1291995
BS-20040-4-15.875	200	40	15.875	4	270	419373	1767994
DBS-20040-3-15.875	200	40	15.875	3	270	321835	1291995
DBS-20040-4-15.875	200	40	15.875	4	270	419373	1767994
BS-20040-3-19.05	200	40	19.050	3	280	417431	1566744
BS-20040-4-19.05	200	40	19.050	4	280	545684	2154272
DBS-20040-3-19.05	200	40	19.050	3	280	417431	1566744
DBS-20040-4-19.05	200	40	19.050	4	280	545684	2154272
BS-2510-2-4.76	25	10	4.760	2	40	15270	26355
KBS-2510	25	10	4.760	4	40	27739	52754
BS-2510-4-4.76	25	10	4.760	4	40	27716	52710
KBS-2510	25	10	4.760	4	40	27739	52754
EDBS-2510	25	10	4.760	3	40	21641	39532
DBS-2510-2-4.76	25	10	4.760	2	40	15270	26355
EDBS-2510	25	10	4.760	3	40	21641	39532
DBS-2510-4-4.76	25	10	4.760	4	40	27716	52710
RBS-2510	25	10	6.350	3	48	29243	48719
RS-2510	25	10	6.350	3	48	29243	48719
BS-2502-4-1.5875	25	2	1.588	4	40	7294	22249
DBS-2502-4-1.5875	25	2	1.588	4	40	7294	22249
KBS-2520	25	20	3.500	2	40	11764	23589
BS-2520-3-3.5	25	20	3.500	3	40	16671	35383
BSL-2520	25	20	3.500	2	40	11764	23589
KBS-2520	25	20	3.500	2	40	11764	23589
EDBS-2520	25	20	3.500	2	40	11764	23589
EDBS-2520	25	20	3.500	2	40	11764	23589
DBS-2520-3-3.5	25	20	3.500	3	40	16671	35383
BSR-2525-S	25	25	3.500	2	48	11703	23222
BSR-2525-H	25	25	3.500	4	48	21240	46445
BS-2525-2-3.5	25	25	3.500	2	40	11703	23222
BS-2525-4-3.5	25	25	3.500	4	40	21240	46445
BSL-2525	25	25	3.500	2	40	11703	23222
DBS-2525-2-3.5	25	25	3.500	2	40	11703	23222
BS-2504-2-2.381	25	4	2.381	2	40	6390	14287
BS-2504-3-2.381	25	4	2.381	3	40	9055	21430
BS-2504-4-2.381	25	4	2.381	4	40	11598	28574
DBS-2504-2-2.381	25	4	2.381	2	40	6390	14287
DBS-2504-3-2.381	25	4	2.381	3	40	9055	21430
DBS-2504-4-2.381	25	4	2.381	4	40	11598	28574
BS-2505-2-3.5	25	5	3.500	2	40	10765	20935
KBS-2505	25	5	3.500	4	40	19695	41863
BS-2505-4-3.5	25	5	3.500	4	40	19540	41870
RBS-2505	25	5	3.500	3	40	15256	31402
RS-2505	25	5	3.500	3	40	15256	31402
UDBS-2505	25	5	3.500	3	40	15256	31402
KBS-2505	25	5	3.500	4	40	19695	41863
EDBS-2505	25	5	3.500	4	40	19540	41870
DBS-2505-2-3.5	25	5	3.500	2	40	10765	20935
EDBS-2505	25	5	3.500	4	40	19540	41870
DBS-2505-4-3.5	25	5	3.500	4	40	19540	41870
BS-2550-2-3.5	25	50	3.500	2	40	11604	21655
BS-2506-2-3.969	25	6	3.969	2	40	12310	22653
BS-2506-3-3.969	25	6	3.969	3	40	17446	33980
BS-2506-4-3.969	25	6	3.969	4	40	22343	45307
DBS-2506-2-3.969	25	6	3.969	2	40	12310	22653
DBS-2506-3-3.969	25	6	3.969	3	40	17446	33980
DBS-2506-4-3.969	25	6	3.969	4	40	22343	45307
KBS-3210	32	10	6.350	4	50	44429	86829
BS-3210-4-6.35	32	10	6.350	4	50	44429	86829
BS-3210-5-6.35	32	10	6.350	5	50	53829	108537
RBS-3210	32	10	6.350	3	54	34691	65122
RS-3210	32	10	6.350	3	54	34691	65122
UDBS-3210	32	10	6.350	3	54	34691	65122
KBS-3210	32	10	6.350	4	50	44429	86829
EDBS-3210	32	10	6.350	3	50	34691	65122
EDBS-3210	32	10	6.350	3	50	34691	65122
DBS-3210-4-6.35	32	10	6.350	4	50	44429	86829
DBS-3210-5-6.35	32	10	6.350	5	50	53829	108537
DBS-3202-4-1,5875	32	2	1.000	4	50	8053	28609
BS-3202-4-1.5875	32	2	1.588	4	50	8053	28609
BS-3220-2-3.969	32	20	3.969	2	50	15281	33463
KBS-3220	32	20	3.969	3	50	22068	51590
BSL-3220	32	20	3.969	3	50	22056	51590
KBS-3220	32	20	3.969	3	50	22068	51590
EDBS-3220	32	20	3.969	3	50	22254	51590
DBS-3220-2-3.969	32	20	3.969	2	50	15281	33463
EDBS-3220	32	20	3.969	3	50	22254	51590
BS-3220-3-4.762	32	20	4.762	3	56	28234	62241
DBS-3220-3-4.762	32	20	4.762	3	56	28234	62241
BS-3220-6-4.762	32	20	4.762	6	56	51245	124481
BS-3225-3-4.762	32	25	4.762	3	56	28143	61643
BS-3225-4-4.762	32	25	4.762	4	56	36429	83516
DBS-3225-3-4.762	32	25	4.762	3	56	28143	61643
DBS-3225-4-4.762	32	25	4.762	4	56	36429	83516
BS-3225-6-4.762	32	25	4.762	6	56	51080	123285
BSR-3232-S	32	32	3.969	2	58	15563	33937
BSR-3232-H	32	32	3.969	4	58	28248	67874
KBS-3232	32	32	3.969	2	50	15563	33937
BSL-3232	32	32	3.969	2	50	15563	33937
KBS-3232	32	32	3.969	2	50	15563	33937
EDBS-3232	32	32	3.969	2	50	15563	33937
EDBS-3232	32	32	3.969	2	50	15563	33937
BS-3204-3-2.381	32	4	2.381	3	50	10418	29098
BS-3204-4-2.381	32	4	2.381	4	50	13343	38797
BS-3204-5-2.381	32	4	2.381	5	50	16165	48496
DBS-3204-3-2.381	32	4	2.381	3	50	10418	29098
DBS-3204-4-2.381	32	4	2.381	4	50	13343	38797
DBS-3204-5-2.381	32	4	2.381	5	50	16165	48496
BS-3240-2-4.762	32	40	4.762	2	56	19806	40129
BS-3240-4-4.762	32	40	4.762	4	56	35949	80257
BS-3205-3-3.5	32	5	3.500	3	50	17365	41348
KBS-3205	32	5	3.500	5	50	26944	68913
BS-3205-5-3.5	32	5	3.500	5	50	26944	68913
RBS-3205	32	5	3.500	4	48	22239	55131
RS-3205	32	5	3.500	4	48	22239	55131
UDBS-3205	32	5	3.500	4	48	22239	55131
KBS-3205	32	5	3.500	5	50	26944	68913
EDBS-3205	32	5	3.500	5	50	26944	68913
DBS-3205-3-3.5	32	5	3.500	3	50	17365	41348
EDBS-3205	32	5	3.500	5	50	26944	68913
DBS-3205-5-3.5	32	5	3.500	5	50	26944	68913
BS-3206-3-3.969	32	6	3.969	3	50	20548	46769
BS-3206-4-3.969	32	6	3.969	4	50	26315	62358
BS-3206-5-3.969	32	6	3.969	5	50	31883	77948
DBS-3206-3-3.969	32	6	3.969	3	50	20548	46769
DBS-3206-4-3.969	32	6	3.969	4	50	26315	62358
DBS-3206-5-3.969	32	6	3.969	5	50	31883	77948
BS-3208-3-4.762	32	8	4.762	3	50	25876	55016
BS-3208-4-4.762	32	8	4.762	4	50	33140	73355
BS-3208-5-4.762	32	8	4.762	5	50	40151	91694
DBS-3208-3-4.762	32	8	4.762	3	50	25876	55016
DBS-3208-4-4.762	32	8	4.762	4	50	33140	73355
DBS-3208-5-4.762	32	8	4.762	5	50	40151	91694
DBS-4010-3-6.35	40	10	6.350	3	63	40643	86959
EDBS-4010	40	10	6.350	4	63	52050	115945
DBS-4010-5-6.35	40	10	6.350	5	63	63063	144931
DBS-4010-6-6.35	40	10	6.350	6	63	73768	173917
BS-4010-3-6.35	40	10	6.350	3	63	40643	86959
KBS-4010	40	10	6.350	5	63	63062	144931
BS-4010-5-6.35	40	10	6.350	5	63	63063	144931
BS-4010-6-6.35	40	10	6.350	6	63	73768	173917
RBS-4010	40	10	6.350	4	62	52051	115945
RS-4010	40	10	6.350	4	62	52051	115945
UDBS-4010	40	10	6.350	5	62	63062	144931
KBS-4010	40	10	6.350	5	63	63062	144931
EDBS-4010	40	10	6.350	4	63	52050	115945
DBS-4012-3-6.35	40	12	6.350	3	63	40625	86850
DBS-4012-4-6.35	40	12	6.350	4	63	52029	115800
DBS-4012-5-6.35	40	12	6.350	5	63	63036	144750
BS-4012-3-6.35	40	12	6.350	3	63	40625	86850
BS-4012-4-6.35	40	12	6.350	4	63	52029	115800
BS-4012-5-6.35	40	12	6.350	5	63	63036	144750
BS-4016-2-7.938	40	16	7.938	2	70	40556	78923
BS-4016-3-7.938	40	16	7.938	3	70	57478	118384
BS-4016-4-7.938	40	16	7.938	4	70	77076	169120
DBS-4016-2-7.938	40	16	7.938	2	70	40556	78923
DBS-4016-3-7.938	40	16	7.938	3	70	57478	118384
DBS-4016-4-7.938	40	16	7.938	4	70	77076	169120
DBS-4020-2-6.35	40	20	6.350	2	63	31194	64596
EDBS-4020	40	20	6.350	3	63	45294	100483
DBS-4020-4-6.35	40	20	6.350	4	63	58696	136370
BS-4020-2-6.35	40	20	6.350	2	63	31194	64596
KBS-4020	40	20	6.350	3	63	45294	100483
BS-4020-4-6.35	40	20	6.350	4	63	58696	136370
BS-4020-6-6.35	40	20	6.350	6	63	82211	200966
BS-4020-8-6.35	40	20	6.350	8	63	106536	272740
BSL-4020	40	20	6.350	3	63	45294	100483
KBS-4020	40	20	6.350	3	63	45294	100483
EDBS-4020	40	20	6.350	3	63	45294	100483
BS-4020-2-7.938	40	20	7.938	2	70	40503	78606
BS-4020-3-7.938	40	20	7.938	3	70	57400	117909
BS-4020-4-7.938	40	20	7.938	4	70	76973	168442
DBS-4020-2-7.938	40	20	7.938	2	70	40503	78606
DBS-4020-3-7.938	40	20	7.938	3	70	57400	117909
DBS-4020-4-7.938	40	20	7.938	4	70	76973	168442
BS-4025-3-6.35	40	25	6.350	3	63	45190	99795
BS-4025-4-6.35	40	25	6.350	4	63	58563	135437
DBS-4025-3-6.35	40	25	6.350	3	63	45190	99795
DBS-4025-4-6.35	40	25	6.350	4	63	58563	135437
BS-4025-6-6.35	40	25	6.350	6	63	82023	199591
BS-4025-8-6.35	40	25	6.350	8	63	106294	270873
BS-4025-2-7.938	40	25	7.938	2	70	40418	78119
BS-4025-3-7.938	40	25	7.938	3	70	57281	117178
BS-4025-4-7.938	40	25	7.938	4	70	76814	167397
DBS-4025-2-7.938	40	25	7.938	2	70	40418	78119
DBS-4025-3-7.938	40	25	7.938	3	70	57281	117178
DBS-4025-4-7.938	40	25	7.938	4	70	76814	167397
BS-4030-3-6.35	40	30	6.350	3	63	45066	98974
BS-4030-4-6.35	40	30	6.350	4	63	58401	134322
DBS-4030-3-6.35	40	30	6.350	3	63	45066	98974
DBS-4030-4-6.35	40	30	6.350	4	63	58401	134322
BS-4030-6-6.35	40	30	6.350	6	63	81798	197947
BS-4030-8-6.35	40	30	6.350	8	63	106001	268643
BS-4030-2-7.938	40	30	7.938	2	70	42215	83073
BS-4030-3-7.938	40	30	7.938	3	70	59828	124610
BS-4030-4-7.938	40	30	7.938	4	70	79990	177223
DBS-4030-2-7.938	40	30	7.938	2	70	42215	83073
DBS-4030-3-7.938	40	30	7.938	3	70	59828	124610
DBS-4030-4-7.938	40	30	7.938	4	70	79990	177223
EDBS-4040	40	40	6.350	2	63	30826	62338
BSR-4040-S	40	40	6.350	2	72	30826	62338
BSR-4040-H	40	40	6.350	4	72	55951	124677
KBS-4040	40	40	6.350	2	63	30826	62338
BS-4040-4-6.35	40	40	6.350	4	63	55951	124677
BSL-4040	40	40	6.350	2	63	30826	62338
KBS-4040	40	40	6.350	2	63	30826	62338
EDBS-4040	40	40	6.350	2	63	30826	62338
BS-4040-2-7.938	40	40	7.938	2	70	41954	81543
DBS-4040-2-7.938	40	40	7.938	2	70	41954	81543
BS-4005-3-3.5	40	5	3.500	3	63	19385	52947
BS-4005-4-3.5	40	5	3.500	4	63	24826	70596
KBS-4005	40	5	3.500	5	63	30078	88245
BS-4005-6-3.5	40	5	3.500	6	63	35184	105894
RBS-4005	40	5	3.500	5	56	30078	88245
RS-4005	40	5	3.500	5	56	30078	88245
UDBS-4005	40	5	3.500	5	56	30078	88245
KBS-4005	40	5	3.500	5	63	30078	88245
EDBS-4005	40	5	3.500	6	63	35183	105894
DBS-4005-3-3.5	40	5	3.500	3	63	19385	52947
DBS-4005-4-3.5	40	5	3.500	4	63	24826	70596
EDBS-4005	40	5	3.500	6	63	35183	105894
DBS-4005-6-3.5	40	5	3.500	6	63	35184	105894
BS-4006-3-3.969	40	6	3.969	3	63	22921	59558
BS-4006-4-3.969	40	6	3.969	4	63	29356	79411
BS-4006-5-3.969	40	6	3.969	5	63	35566	99263
BS-4006-6-3.969	40	6	3.969	6	63	41604	119116
DBS-4006-3-3.969	40	6	3.969	3	63	22921	59558
DBS-4006-4-3.969	40	6	3.969	4	63	29356	79411
DBS-4006-5-3.969	40	6	3.969	5	63	35566	99263
DBS-4006-6-3.969	40	6	3.969	6	63	41604	119116
BS-4060-2-6.35	40	60	6.350	2	63	31386	62330
BS-4060-4-6.35	40	60	6.350	4	63	56966	124661
DBS-4008-3-4.762	40	8	4.762	3	63	29105	70368
DBS-4008-4-4.762	40	8	4.762	4	63	37275	93825
DBS-4008-5-4.762	40	8	4.762	5	63	45160	117281
DBS-4008-6-4.762	40	8	4.762	6	63	52826	140737
BS-4008-3-4.762	40	8	4.762	3	63	29105	70368
BS-4008-4-4.762	40	8	4.762	4	63	37275	93825
BS-4008-5-4.762	40	8	4.762	5	63	45160	117281
BS-4008-6-4.762	40	8	4.762	6	63	52826	140737
BS-4080-2-6.35	40	80	6.350	2	63	32809	64415
BS-4080-4-6.35	40	80	6.350	4	63	59549	128831
DBS-5010-3-7.144	50	10	7.144	3	75	53384	123944
DBS-5010-4-7.144	50	10	7.144	4	75	68368	165259
EDBS-5010	50	10	7.144	6	75	96893	247889
DBS-5010-6-7.144	50	10	7.144	6	75	96893	247889
BS-5010-3-7.144	50	10	7.144	3	75	53384	123944
BS-5010-4-7.144	50	10	7.144	4	75	68368	165259
KBS-5010	50	10	7.144	6	75	96893	247889
BS-5010-6-7.144	50	10	7.144	6	75	96893	247889
RBS-5010	50	10	7.144	5	72	82831	206574
RS-5010	50	10	7.144	5	72	82831	206574
UDBS-5010	50	10	7.144	5	72	82799	206575
KBS-5010	50	10	7.144	6	75	96893	247889
EDBS-5010	50	10	7.144	6	75	96893	247889
BS-50100-2-7.144	50	100	7.144	2	75	41033	85352
DBS-5012-3-7.938	50	12	7.938	3	75	60835	135915
DBS-5012-4-7.938	50	12	7.938	4	75	77910	181219
DBS-5012-5-7.938	50	12	7.938	5	75	94393	226524
BS-5012-3-7.938	50	12	7.938	3	75	60835	135915
BS-5012-4-7.938	50	12	7.938	4	75	77910	181219
BS-5012-5-7.938	50	12	7.938	5	75	94393	226524
DBS-5016-2-7.144	50	16	7.144	2	75	37631	82390
DBS-5016-3-7.144	50	16	7.144	3	75	53331	123585
DBS-5016-4-7.144	50	16	7.144	4	75	68301	164780
DBS-5016-5-7.144	50	16	7.144	5	75	82751	205975
BS-5016-2-7.144	50	16	7.144	2	75	37631	82390
BS-5016-3-7.144	50	16	7.144	3	75	53331	123585
BS-5016-4-7.144	50	16	7.144	4	75	68301	164780
BS-5016-5-7.144	50	16	7.144	5	75	82751	205975
BS-5016-2-7.938	50	16	7.938	2	82	46400	101725
BS-5016-3-7.938	50	16	7.938	3	82	65759	152588
BS-5016-4-7.938	50	16	7.938	4	82	87308	214754
BS-5016-5-7.938	50	16	7.938	5	82	105778	268442
DBS-5016-2-7.938	50	16	7.938	2	82	46400	101725
DBS-5016-3-7.938	50	16	7.938	3	82	65759	152588
DBS-5016-4-7.938	50	16	7.938	4	82	87308	214754
DBS-5016-5-7.938	50	16	7.938	5	82	105778	268442
DBS-5020-3-7.144	50	20	7.144	3	75	58874	141431
DBS-5020-4-7.144	50	20	7.144	4	75	76209	191616
EDBS-5020	50	20	7.144	5	75	92916	241802
BS-5020-3-7.144	50	20	7.144	3	75	58874	141431
BS-5020-4-7.144	50	20	7.144	4	75	76209	191616
KBS-5020	50	20	7.144	5	75	92916	241802
BSL-5020	50	20	7.144	5	75	92916	241802
KBS-5020	50	20	7.144	5	75	92916	241802
EDBS-5020	50	20	7.144	5	75	92916	241802
BS-5020-3-7.938	50	20	7.938	3	82	65700	152185
BS-5020-4-7.938	50	20	7.938	4	82	87231	214186
BS-5020-5-7.938	50	20	7.938	5	82	105685	267733
DBS-5020-3-7.938	50	20	7.938	3	82	65700	152185
DBS-5020-4-7.938	50	20	7.938	4	82	87231	214186
DBS-5020-5-7.938	50	20	7.938	5	82	105685	267733
BS-5025-4-7.144	50	25	7.144	4	75	76095	190762
DBS-5025-4-7.144	50	25	7.144	4	75	76095	190762
BS-5025-6-7.144	50	25	7.144	6	75	106700	281601
BS-5025-8-7.144	50	25	7.144	8	75	138116	381525
BS-5025-3-7.938	50	25	7.938	3	82	65611	151562
BS-5025-4-7.938	50	25	7.938	4	82	87111	213309
BS-5025-5-7.938	50	25	7.938	5	82	105540	266636
DBS-5025-3-7.938	50	25	7.938	3	82	65611	151562
DBS-5025-4-7.938	50	25	7.938	4	82	87111	213309
DBS-5025-5-7.938	50	25	7.938	5	82	105540	266636
BS-5030-4-7.144	50	30	7.144	4	75	75959	189734
DBS-5030-4-7.144	50	30	7.144	4	75	75959	189734
BS-5030-6-7.144	50	30	7.144	6	75	106508	280083
BS-5030-8-7.144	50	30	7.144	8	75	137868	379468
BS-5030-2-7.938	50	30	7.938	2	82	47915	106126
BS-5030-3-7.938	50	30	7.938	3	82	67906	159188
DBS-5030-2-7.938	50	30	7.938	2	82	47915	106126
DBS-5030-3-7.938	50	30	7.938	3	82	67906	159188
BS-5035-6-7.144	50	35	7.144	6	75	106284	278320
BS-5035-8-7.144	50	35	7.144	8	75	137578	377079
BS-5035-4-7.938	50	35	7.938	4	82	89819	222127
DBS-5035-4-7.938	50	35	7.938	4	82	89819	222127
DBS-5040-2-7.144	50	40	7.144	2	75	40329	89138
BS-5040-2-7.144	50	40	7.144	2	75	40329	89138
BS-5040-2-7.938	50	40	7.938	2	82	47716	104814
DBS-5040-2-7.938	50	40	7.938	2	82	47716	104814
DBS-5005-3-3.5	50	5	3.500	3	75	21568	67857
DBS-5005-4-3.5	50	5	3.500	4	75	27623	90475
EDBS-5005	50	5	3.500	6	75	39147	135713
DBS-5005-6-3.5	50	5	3.500	6	75	39146	135713
BS-5005-3-3.5	50	5	3.500	3	75	21568	67857
BS-5005-4-3.5	50	5	3.500	4	75	27623	90475
KBS-5005	50	5	3.500	5	75	33465	113094
BS-5005-6-3.5	50	5	3.500	6	75	39146	135713
RBS-5005	50	5	3.500	5	70	33465	113094
RS-5005	50	5	3.500	5	70	33465	113094
KBS-5005	50	5	3.500	5	75	33465	113094
EDBS-5005	50	5	3.500	6	75	39147	135713
BSR-5050-S	50	50	7.144	2	88	41429	92032
BSR-5050-H	50	50	7.144	4	88	75194	184063
BS-5050-2-7.144	50	50	7.144	2	75	41429	92032
BS-5050-4-7.144	50	50	7.144	4	75	75194	184063
BSL-5050	50	50	7.144	2	75	41429	92032
DBS-5006-3-3.969	50	6	3.969	3	75	25619	76603
DBS-5006-4-3.969	50	6	3.969	4	75	32810	102138
DBS-5006-5-3.969	50	6	3.969	5	75	39751	127672
DBS-5006-6-3.969	50	6	3.969	6	75	46500	153207
BS-5006-3-3.969	50	6	3.969	3	75	25619	76603
BS-5006-4-3.969	50	6	3.969	4	75	32810	102138
BS-5006-5-3.969	50	6	3.969	5	75	39751	127672
BS-5006-6-3.969	50	6	3.969	6	75	46500	153207
DBS-5008-3-4.762	50	8	4.762	3	75	32971	91845
DBS-5008-4-4.762	50	8	4.762	4	75	42228	122460
DBS-5008-5-4.762	50	8	4.762	5	75	51160	153075
DBS-5008-6-4.762	50	8	4.762	6	75	59845	183690
BS-5008-3-4.762	50	8	4.762	3	75	32971	91845
BS-5008-4-4.762	50	8	4.762	4	75	42228	122460
BS-5008-5-4.762	50	8	4.762	5	75	51160	153075
BS-5008-6-4.762	50	8	4.762	6	75	59845	183690
DBS-6310-3-7.144	63	10	7.144	3	90	61563	165370
DBS-6310-4-7.144	63	10	7.144	4	90	78843	220494
EDBS-6310	63	10	7.144	6	90	111739	330741
DBS-6310-6-7.144	63	10	7.144	6	90	111738	330741
BS-6310-3-7.144	63	10	7.144	3	90	61563	165370
BS-6310-4-7.144	63	10	7.144	4	90	78843	220494
KBS-6310	63	10	7.144	5	90	95523	275617
BS-6310-6-7.144	63	10	7.144	6	90	111738	330741
RBS-6310	63	10	7.144	6	85	111739	330741
RS-6310	63	10	7.144	5	85	95523	275617
UDBS-6310	63	10	7.144	6	85	111739	330741
KBS-6310	63	10	7.144	5	90	95523	275617
EDBS-6310	63	10	7.144	6	90	111739	330741
DBS-6312-3-7.938	63	12	7.938	3	90	69696	178559
DBS-6312-4-7.938	63	12	7.938	4	90	89259	238078
DBS-6312-5-7.938	63	12	7.938	5	90	108143	297598
DBS-6312-6-7.938	63	12	7.938	6	90	126500	357117
BS-6312-3-7.938	63	12	7.938	3	90	69696	178559
BS-6312-4-7.938	63	12	7.938	4	90	89259	238078
BS-6312-5-7.938	63	12	7.938	5	90	108143	297598
BS-6312-6-7.938	63	12	7.938	6	90	126500	357117
DBS-6316-3-7.144	63	16	7.144	3	95	66001	183403
DBS-6316-4-7.144	63	16	7.144	4	95	85230	247594
DBS-6316-5-7.144	63	16	7.144	5	95	103770	311785
DBS-6316-6-7.144	63	16	7.144	6	95	121783	375976
BS-6316-3-7.144	63	16	7.144	3	95	66001	183403
BS-6316-4-7.144	63	16	7.144	4	95	66001	183403
BS-6316-5-7.144	63	16	7.144	5	95	103770	311785
BS-6316-6-7.144	63	16	7.144	6	95	121783	375976
BS-6316-3-9.525	63	16	9.525	3	105	93873	232307
BS-6316-4-9.525	63	16	9.525	4	105	124404	326045
BS-6316-5-9.525	63	16	9.525	5	105	150723	407556
BS-6316-6-9.525	63	16	9.525	6	105	176309	489067
DBS-6316-3-9.525	63	16	9.525	3	105	93873	232307
DBS-6316-4-9.525	63	16	9.525	4	105	124404	326045
DBS-6316-5-9.525	63	16	9.525	5	105	150723	407556
DBS-6316-6-9.525	63	16	9.525	6	105	176309	489067
DBS-6320-3-7.144	63	20	7.144	3	95	65964	183089
DBS-6320-4-7.144	63	20	7.144	4	95	85181	247170
EDBS-6320	63	20	7.144	5	95	103711	311251
DBS-6320-6-7.144	63	20	7.144	6	95	121714	375332
BS-6320-3-7.144	63	20	7.144	3	95	65964	183089
BS-6320-4-7.144	63	20	7.144	4	95	85181	247170
KBS-6320	63	20	7.144	5	95	103711	311251
BS-6320-6-7.144	63	20	7.144	6	95	121714	375332
BSL-6320	63	20	7.144	5	95	103711	311251
KBS-6320	63	20	7.144	5	95	103711	311251
EDBS-6320	63	20	7.144	5	95	103711	311251
DBS-6320-4-9.525	63	20	9.525	4	105	124335	325497
DBS-6320-5-9.525	63	20	9.525	5	105	150638	406871
DBS-6320-6-9.525	63	20	9.525	6	105	176210	488245
BS-6320-3-9.525	63	20	9.525	3	105	93820	231916
BS-6320-4-9.525	63	20	9.525	4	105	124335	325497
BS-6320-5-9.525	63	20	9.525	5	105	150638	406871
BS-6320-6-9.525	63	20	9.525	6	105	176210	488245
DBS-6320-3-9.525	63	20	9.525	3	105	93820	231916
BS-6325-4-7.144	63	25	7.144	4	95	85106	246512
DBS-6325-4-7.144	63	25	7.144	4	95	85106	246512
BS-6325-6-7.144	63	25	7.144	6	95	119620	365203
BS-6325-8-7.144	63	25	7.144	8	95	154471	493024
DBS-6325-2-9.525	63	25	9.525	2	105	66141	154207
DBS-6325-3-9.525	63	25	9.525	3	105	93738	231310
DBS-6325-4-9.525	63	25	9.525	4	105	124226	324646
DBS-6325-5-9.525	63	25	9.525	5	105	150506	405808
BS-6325-2-9.525	63	25	9.525	2	105	66141	154207
BS-6325-3-9.525	63	25	9.525	3	105	93738	231310
BS-6325-4-9.525	63	25	9.525	4	105	124226	324646
BS-6325-5-9.525	63	25	9.525	5	105	150506	405808
BS-6330-4-7.144	63	30	7.144	4	95	85014	245715
DBS-6330-4-7.144	63	30	7.144	4	95	85014	245715
DBS-6330-2-9.525	63	30	9.525	2	105	66071	153717
DBS-6330-3-9.525	63	30	9.525	3	105	93639	230576
DBS-6330-4-9.525	63	30	9.525	4	105	124095	323615
BS-6330-2-9.525	63	30	9.525	2	105	66071	153717
BS-6330-3-9.525	63	30	9.525	3	105	93639	230576
BS-6330-4-9.525	63	30	9.525	4	105	124095	323615
BS-6335-6-7.144	63	35	7.144	6	95	122305	376241
BS-6335-8-7.144	63	35	7.144	8	95	157891	507699
DBS-6340-2-7.144	63	40	7.144	2	95	46711	121860
DBS-6340-3-7.144	63	40	7.144	3	95	67286	187304
BS-6340-4-7.144	63	40	7.144	4	95	84784	243721
BS-6340-6-7.144	63	40	7.144	6	95	122128	374608
BS-6340-2-7.144	63	40	7.144	2	95	46711	121860
BS-6340-3-7.144	63	40	7.144	3	95	67286	187304
DBS-6340-2-9.525	63	40	9.525	2	105	68188	160517
DBS-6340-3-9.525	63	40	9.525	3	105	96638	240776
BS-6340-2-9.525	63	40	9.525	2	105	68188	160517
BS-6340-3-9.525	63	40	9.525	3	105	96638	240776
DBS-6305-3-3.5	63	5	3.500	3	90	24021	87733
DBS-6305-4-3.5	63	5	3.500	4	90	30764	116977
EDBS-6305	63	5	3.500	5	90	37273	146221
DBS-6305-6-3.5	63	5	3.500	6	90	43599	175465
BS-6305-3-3.5	63	5	3.500	3	90	24021	87733
BS-6305-4-3.5	63	5	3.500	4	90	30764	116977
KBS-6305	63	5	3.500	5	90	37273	146221
BS-6305-6-3.5	63	5	3.500	6	90	43599	175465
KBS-6305	63	5	3.500	5	90	37273	146221
EDBS-6305	63	5	3.500	5	90	37273	146221
BS-6350-4-7.144	63	50	7.144	4	95	84494	241227
DBS-6306-3-3.969	63	6	3.969	3	90	28359	97907
DBS-6306-4-3.969	63	6	3.969	4	90	36319	130542
DBS-6306-5-3.969	63	6	3.969	5	90	44001	163178
DBS-6306-6-3.969	63	6	3.969	6	90	51471	195813
BS-6306-3-3.969	63	6	3.969	3	90	28359	97907
BS-6306-4-3.969	63	6	3.969	4	90	36319	130542
BS-6306-5-3.969	63	6	3.969	5	90	44001	163178
BS-6306-6-3.969	63	6	3.969	6	90	51471	195813
DBS-8010-4-7.144	80	10	7.144	4	105	90153	294122
DBS-8010-5-7.144	80	10	7.144	5	105	109225	367653
EDBS-8010	80	10	7.144	6	105	127764	441184
BS-8010-4-7.144	80	10	7.144	4	105	90153	294122
BS-8010-5-7.144	80	10	7.144	5	105	109225	367653
BS-8010-6-7.144	80	10	7.144	6	105	127766	441184
EDBS-8010	80	10	7.144	6	105	127764	441184
DBS-8012-4-7.938	80	12	7.938	4	105	102348	317639
DBS-8012-5-7.938	80	12	7.938	5	105	123999	397049
DBS-8012-6-7.938	80	12	7.938	6	105	145049	476459
BS-8012-4-7.938	80	12	7.938	4	105	102348	317639
BS-8012-5-7.938	80	12	7.938	5	105	123999	397049
BS-8012-6-7.938	80	12	7.938	6	105	145049	476459
BS-8016-4-12.7	80	16	12.700	4	135	203366	551301
BS-8016-5-12.7	80	16	12.700	5	135	248115	696380
BS-8016-6-12.7	80	16	12.700	6	135	291578	841459
DBS-8016-4-12.7	80	16	12.700	4	135	203366	551301
DBS-8016-5-12.7	80	16	12.700	5	135	248115	696380
DBS-8016-6-12.7	80	16	12.700	6	135	291578	841459
DBS-8016-4-9.525	80	16	9.525	4	125	126245	359047
DBS-8016-5-9.525	80	16	9.525	5	125	152953	448808
DBS-8016-6-9.525	80	16	9.525	6	125	178916	538570
BS-8016-4-9.525	80	16	9.525	4	125	126245	359047
BS-8016-5-9.525	80	16	9.525	5	125	152953	448808
BS-8016-6-9.525	80	16	9.525	6	125	178916	538570
DBS-8020-3-12.7	80	20	12.700	3	135	153119	391312
DBS-8020-4-12.7	80	20	12.700	4	135	203296	550735
DBS-8020-5-12.7	80	20	12.700	5	135	246305	688419
DBS-8020-6-12.7	80	20	12.700	6	135	288118	826102
BS-8020-3-12.7	80	20	12.700	3	135	153119	391312
BS-8020-4-12.7	80	20	12.700	4	135	203296	550735
BS-8020-5-12.7	80	20	12.700	5	135	246305	688419
BS-8020-6-12.7	80	20	12.700	6	135	288118	826102
DBS-8020-3-9.525	80	20	9.525	3	125	109205	313832
DBS-8020-4-9.525	80	20	9.525	4	125	141068	423877
EDBS-8020	80	20	9.525	5	125	171786	533922
DBS-8020-6-9.525	80	20	9.525	6	125	201629	643966
BS-8020-3-9.525	80	20	9.525	3	125	109205	313832
BS-8020-4-9.525	80	20	9.525	4	125	141068	423877
BS-8020-5-9.525	80	20	9.525	5	125	171786	533922
BS-8020-6-9.525	80	20	9.525	6	125	201629	643966
EDBS-8020	80	20	9.525	5	125	171786	533922
DBS-8025-2-12.7	80	25	12.700	2	135	153038	390686
DBS-8025-3-12.7	80	25	12.700	3	135	153038	390686
DBS-8025-4-12.7	80	25	12.700	4	135	203189	549854
DBS-8025-5-12.7	80	25	12.700	5	135	246174	687318
BS-8025-2-12.7	80	25	12.700	2	135	107984	260457
BS-8025-3-12.7	80	25	12.700	3	135	153038	390686
BS-8025-4-12.7	80	25	12.700	4	135	203189	549854
BS-8025-5-12.7	80	25	12.700	5	135	246174	687318
DBS-8030-2-12.7	80	30	12.700	2	135	107914	259950
DBS-8030-3-12.7	80	30	12.700	3	135	152938	389926
DBS-8030-4-12.7	80	30	12.700	4	135	203056	548784
BS-8030-2-12.7	80	30	12.700	2	135	107914	259950
BS-8030-3-12.7	80	30	12.700	3	135	152938	389926
BS-8030-4-12.7	80	30	12.700	4	135	203056	548784
BS-8030-4-9.525	80	30	9.000	4	125	140894	422321
BS-8030-2-9.525	80	30	9.525	2	125	75623	203039
BS-8030-3-9.525	80	30	9.525	3	125	109071	312680
DBS-8030-2-9.525	80	30	9.525	2	125	75623	203039
DBS-8030-3-9.525	80	30	9.525	3	125	109071	312680
DBS-8030-4-9.525	80	30	9.525	4	125	140894	422321
DBS-8040-2-12.7	80	40	12.700	2	135	111691	273044
DBS-8040-3-12.7	80	40	12.700	3	135	158291	409566
DBS-8040-4-12.7	80	40	12.700	4	135	209775	574829
BS-8040-2-12.7	80	40	12.700	2	135	111691	273044
BS-8040-3-12.7	80	40	12.700	3	135	158291	409566
BS-8040-4-12.7	80	40	12.700	4	135	209775	574829
DBS-8040-2-9.525	80	40	9.525	2	125	75494	202005
DBS-8040-3-9.525	80	40	9.525	3	125	108886	311088
DBS-8040-4-9.525	80	40	9.525	4	125	140655	420171
BS-8040-2-9.525	80	40	9.525	2	125	75494	202005
BS-8040-3-9.525	80	40	9.525	3	125	108886	311088
BS-8040-4-9.525	80	40	9.525	4	125	140655	420171
BS-8005-5-3.5	80	5	3.500	5	105	41133	187626
BS-8005-6-3.5	80	5	3.500	6	105	48115	225151
DBS-8005-5-3.5	80	5	3.500	5	105	41133	187626
DBS-8005-6-3.5	80	5	3.500	6	105	48115	225151
DBS-8064-2-12.7	80	64	12.700	2	135	111054	268393
BS-8064-2-12.7	80	64	12.700	2	135	111054	268393
DBS-8064-2-9.525	80	64	9.525	2	125	77036	206383

ALTA CAPACIDAD

ALTA VELOCIDAD

DIMENSIONAL CASTELLANO-INGLES

DIMENSIONAL ALEMÁN-FRANCÉS

DIMENSIONAL CHINO-INGLÉS

DIMENSIONAL ITALIANO-INGLÉS

HUSILLOS DE RODILLOS ROLLVIS

KRR

PRODUCTOS EICHENBERGER

TÉCNICO ALEMÁN-FRANCÉS

TÉCNICO CASTELLANO-INGLÉS

TUERCA GIRATORIA

Nuestra garantía de calidad

Korta se rige por una exigente política de aseguramiento de calidad, y está certificada por las principales normas internacionales. Contamos con Certificado de Registro de Empresa ER-071/2/96 de acuerdo a la norma UNE-EN ISO 9001.
